QUICK soldering fume absorber with coarse filter and connection for extraction duct, ESD version

Power consumption: 23 watts
Weight: 1.5 kg
Absorber dimensions: 180 x 210 x 280 mm
Fan dimensions: 120 x 120 x 30 mm
Extraction capacity: 64.2 m³/h

The direction of the air flow can be changed using the air flow plate. To do this, slide the round fan cover downwards on the rear and reinsert it from below, above, or from the side.

Scope of delivery:
– QU493 smoke absorber with coarse filter installed
– Connection adapter for extraction duct Ø 100 mm
– Air guide adapter
– 2 replacement coarse filters
