– Suitable for leaded and lead-free soldering
– Very short heating time (approx. 19 seconds to 350°C).
– Automatic standby function selectable from 5 s to 99 min.
– Programmable switch-off function.
– Digital actual and target temperature display
– Calibratable
– Password protection
– Menu navigation in English, German, Czech, Serbian, Vietnamese, Spanish
– 3 preprogrammed fixed temperatures (200°/320°/380°C)
– Temperature can be increased/decreased in 1°C increments
– 2 cleaning options, dry and viscose sponge
– Alarm function for temperature window
– Sensor-controlled real-time monitoring of the temperature at the soldering tip, ensuring excellent temperature control
– Very easy and quick soldering tip replacement
– Soldering iron with 1.2 m flexible silicone connection cable
– ESD protection and ESD test function
When the ESD test function is activated, the station continuously checks whether the station is grounded. If this is not the case, a warning symbol is clearly visible on the display
– Networkable, up to 63 stations can be monitored and programmed via a PC.

In the Soldering Manager System for the Quick TS series, you can view both current soldering temperatures in a real-time query and the soldering temperatures of past soldering processes.
A clear and compact display of all current operating parameters and temperatures is also possible for multiple stations simultaneously.
The soldering station can be switched on and off or put into sleep mode via remote access. All functions and options available on the station itself can also be managed centrally via the Soldering Manager System.

– Display: Color LCD TFT
– Rated power: 90 watts
– Compatible soldering tip series: 200
– Operating voltage: 230 volts / 50 Hz
– Working temperature range: 200 – 420 °C
– Temperature stability: +/- 2°C
– Max. ambient temperature: 40 °C
– Grounding resistance: <2 Ω
– Ground leakage voltage: <2 mV
– Dimensions: W x H x D 137 x 114 x 168 mm
– Weight: 2.5 kg
– Compliance: RoHS, CE
